Efficiency
Cut energy loss at one of the biggest sources: your windows.
Up to a quarter of a typical home’s energy can escape through outdated windows and doors. REHAU uPVC systems are built to keep conditioned air in, outside weather out and energy costs under control.
Better Performance to save money
REHAU windows and doors use multi-chambered uPVC profiles with integrated insulation and glazing capacities up to 2". This design allows for double-, triple- and even quad-pane glass while maintaining a tight, continuous frame.
The result: whole-unit U-values as low as 0.13 Btu/hr·ft²·°F, significantly lower than the approximately 0.37 U-value found in many older residential windows.
- Up to 35% better thermal performance than typical old vinyl windows.
- Generous glazing pockets to support high-performance glass packages.
- Fusion-welded corners for continuous, airtight frames.
- Advanced compression-seal technology to reduce air and water leakage.
The savings can help offset other envelope upgrades while supporting LEED, Passive House and other high-performance building programs.
Das meistprämierte Fenstersystem
ARTEVO
Two numbers worth remembering
25%
energy loss through windows can reach this level in homes with thin, poorly sealed glass and aging frames.
35%
the improvement in energy performance REHAU window and door systems can deliver over older vinyl units.
Maximal groß.
Maximal schön.
Maximal effizient.
Stilvoll. Leistungsstark. Vollkommen.
Fenster neu erfunden. Für das Leben von heute.
Maximal groß.
Maximal schön.
Maximal effizient.
Stilvoll. Leistungsstark. Vollkommen.
Fenster neu erfunden. Für das Leben von heute.
Material
Raw materials are mixed in-house to ensure durability, energy efficiency and sustainability
Material
Raw materials are mixed in-house to ensure durability, energy efficiency and sustainability
Most products are only as good as the material used to make them, which is why the formula for the uPVC (polyvinyl chloride) used in every window and door system at REHAU is a closely held company secret. We mix all raw materials in-house rather than relying on ready-made formulations from outside vendors. The resulting profiles feature qualities not available anywhere else.
Just like the kitchen staff at a fine restaurant, the REHAU “chefs” at our in-house chemistry department are constantly testing and optimizing these formulations to meet the strictest standards.
We meet and exceed the stringent requirements of the American Architectural Manufacturers Association (AAMA) by adjusting our uPVC formulas for each of the widely varying North American climate zones. REHAU’s window and door systems are part of the AAMA Profile Certification Program, assuring consistent quality that is verified by an independent auditor twice a year.
Schallschutz
Our latest breakthrough formula, called RAU-FIPRO, combines both PVC and fiberglass for outstanding strength and load capacities without relying on steel reinforcement. Similar to the fiber-composite materials used in aeronautics, RAU-FIPRO addresses the increasing demand for high efficiency window and door products that hold up in commercial applications.
Sicherheit
UV (ultraviolet) light can break down uPVC, causing it to fade and crack over time. We are constantly testing and improving our formulas for UV stability. So, while most extruders are stingy with titanium dioxide to cut costs, we add more of this expensive ingredient because it is critical to keeping the white WHITE in vinyl windows for decades, no matter the conditions.
..
Extensive weather testing
After extensive weather testing in Arizona (dry climate, high radiation), Florida (humid, hot climate) and Ohio (industrial, moderate climate), REHAU uPVC continuously outperforms standard vinyl with the same like-new color and sheen on day 1,825 (that’s five years) as day one. Given the demand for multiple colors and wood grain/metal-like finishes, we also do extensive comparative testing of our laminate surfacing against other colored, painted, foiled and capstocked (resin coated) windows.
Bis zu
14.000 €
Heizkosten in 15 Jahren sparen.
Bis zu
97 %
Geräuschreduktion.
Bis zu
RC3
Einbruchsicherheit.
Mache mehr aus deinen Fenstern.
Lorem ipsum dolor sit amet, consectetuer adipiscing elit.
Max Height
up to
72'
non-reinforced
Max Height
up to
76'
reinforced
Max Glazing
up to
1 11/16'
glazes
Max Performance
Designed to meet Passive House Standards
Smart Privacy
Lorem ipsum dolor sit amet, consectetuer adipiscing elit. Ut commodo pretium nisl. Integer sit amet lectus. Nam suscipit magna nec nunc.
Smart Privacy
Lorem ipsum dolor sit amet, consectetuer adipiscing elit. Ut commodo pretium nisl. Integer sit amet lectus. Nam suscipit magna nec nunc.
Smart Privacy
Lorem ipsum dolor sit amet, consectetuer adipiscing elit. Ut commodo pretium nisl. Integer sit amet lectus. Nam suscipit magna nec nunc.
Technische Daten
| Ansichtsbreiten Rahmen/Flügel: | 106 mm bis 184 mm (148 mm*) |
| Bautiefe: | 80 mm |
| Wärmedämmung Uf (EN 12412-2 / EN 10077-2): | ARTEVO bis 0,97 W/m²K |
| ARTEVO max bis 0,79 W/m²K | |
| Schalldämmung Rw (EN ISO 717-1): | bis 48 dB |
| Einbruchhemmung (EN 1627): | bis Klasse RC 3 (RC 2*) |
| Windwiderstand (EN 12210): | bis Klasse B5/C5 (bis Klasse C2/B2*) |
| Schlagregendichtigkeit (EN 12208): | bis Klasse 9A (bis Klasse 4A*) |
| Luftdurchlässigkeit (EN 12207): | bis Klasse 4 (bis Klasse 4*) |
| Maximale Scheibenstärke: | 56 mm bzw. 72 mm bei flächenbündigem Flügel |
